Product Description
| Model | D-3004 |
| Type | Power Amplifier |
| 8 ohm/Stereo | 4*3000W |
| 4 ohm/Stereo | 4*5100W |
| 2 ohm/Stereo | 4*8600W |
| 16 ohm/Bridge | 2*6000 W |
| 8 ohm/Bridge | 2*10200W |
| 4 ohm/Bridge | 2*17340W |
| Output RMS Voltage | 154.9v |
| Slew Rate | 50V/us |
| Sensitivity (selectable) | 41dB 38dB,35dB, 32dB |
| THD+N | 0.01% |
| IMD-SMPTE | 0.01% |
| DIME30 | 0.01% |
| Cross-talk | >/= 90dB |
| Frequency response | +/-0.5dB |
| Input impedance | 20k Ohm(balance), 10K ohm (unbalance) |
| Damp Factor | >/=5000(8 ohm, 20Hz-200Hz) |
| SNR | >/=105dB |
| Main Power | 90-260CVAC, 50-60Hz |
| Protection | under voltage,DC, temperature,over load limiter, short protection |
| Size | 483*44*465mm |
| Net Weight | 12kg |
